The Mextru 1300 HT is a high-throughput industrial FGF 3D printer designed for large-scale manufacturing and high-temperature applications. With a 1300 × 1300 × 1300 mm build volume, 400°C three-zone heating, 80°C heated chamber, and 3 kg/h pellet extrusion, it enables fast, cost-effective production of large functional parts, molds, tooling, jigs, and prototypes.
| Mextru 1300 HT | ||
|---|---|---|
|
Printing size: |
1300 * 1300 * 1300 mm |
|
|
Number of Toolheads: |
1 |
|
|
Toolhead Type: |
Screw Extrusion |
|
|
Nozzle Temperature: |
400°C (Three-Zone Heating) |
|
|
Hot Bed Temperature: |
Max 110 °C |
|
|
Constant Chamber Temperature : |
Max 80 °C |
|
|
Spool Box Drying: |
Hopper drying |
|
|
Print Speed: |
3KG/H |
|
|
Spool Size: |
Pellet Materials |
|
|
Auxiliary Feed: |
Vacuum Feeder |
|
|
Thermal Insulation: |
Bellows Cover |
|
|
Machine dimensions: |
2700 * 2116 * 2403mm |
|
|
Package dimensions: |
2800 * 2220 * 2580mm |
|
|
Support Filaments: |
PLA, PETG, ABS, ASA, PC, PA, PP, etc. |
|
|
Build Plate Movement: |
Z-axis (Vertical) |
|
|
Model Cooling: |
Remote Air Supply |
|
|
Extruder/Heat Break Cooling: |
Water Cooling |
|
|
Air Filtration: |
HEPA Filter |
|
|
Electromagnetic Door Lock： |
Yes |
|
|
Door Open Detection: |
Yes |
|
|
Power Rating: |
15000 W |
|
|
Voltage |
Three-Phase Power |
|
|
Motors |
Servo Motors |
|
|
Screen |
15.6-inch |
|
|
AI Detection: |
Yes |
|
|
Firmware |
Klipper |
|
